You want more for your money? Who doesn't! And that's exactly what we're giving you with the Jitney/Walden Speed Shop “Ultimate Hi-Boy Chassis”.

This chassis has many special features that you won't find anywhere else, on anyone else's chassis. It's in a league of its own with the smoothest riding traditional suspension with zero bump steer. Amazing road feel and stability. Two years of development and engineering. It's not just parts pulled off the shelf and slapped together. It is designed and engineered for function and style by the hotrod chassis guru Jim Jacobs himself.

This unique pinched-nose chassis sports the spring behind the axle or “suicide front end”. The front suspension uses the stock heavy ’32 front axle mounted to engineered batwings and hairpins. It boasts many other distinctive features as well, including:

  • A killer stance!
  • Pinched front frame rails with Jitney designed crossmember, shock mounts, headlight bar mount, steering box mount and radiator mounting pads
  • 3/8" thick front boxing plates with integrated steering box mount
  • 3/8" thick internal shock mount plates
  • Engineered center tubular crossmember with 8 point mounting, integrated ladder bar mounts, brake and clutch pedal mounts, and universal sliding transmission mount
  • Kicked up rear frame horns and c-notched frame rails (stock rear of frame also available)
  • Unique curved rear spreader bar to match the contour of the Deuce body
  • Overall wheelbase 107”

All parts are welded in house on our own custom fixtures to guarantee quality and precision. You are buying American made products with a name built on excellence in craftsmanship and an eye for detail. Our parts fit perfectly and they're road tested strong! Contact Us For More Info.





INCUDED:

Wss / Jitney Frame - 7500.00

Suicide Hairpin Kit with SS Early Style Rod Ends - 1025.00

Dropped Heavy I-Beam - 650.00

Forged Steel Bushed  & Reamed Front Spindles - 250.00

SS King Pin Kit with SS Bearings SS Stops & Washers - 110.00

Dropped Steering Arm - 165.00

Steering Arm Bolt Kit - 45.00

16:1 Vega Steering Box - 500.00

Pitman Arm with Nut - 95.00

Drag Link with Standard Tie Rod Ends - 85.00

Tie Rod with Standard Ends 95.00

F100 Style Front Upper Shock Mounts - 120.00

Panhard Bar with Heims & Mounting Hardware (Mounting Tab will be installed on frame) - 125.00

Front Multi Leaf Front Spring (Made to fit Jitney Pinched Suicide Suspension) - 495.00

Ridetech Front Gas Filled Shock - 500.00

Winters Quick Change Early Ford Banjo Style - 4000.00 or

9 Inch Rear End Housing with Ladder Bar & Spring Hanger Installed - 900.00

Ladder Bar Kit with Bushing, Sleeves, & Grade 8 Hardware

Ridetech Rear Gas Shocks with Dust Cover - 560.00

Rear Multi-Leaf Spring  - 300.00

Rear Panhard Bar with Oilite Bushings on Rear Shackle ( Mounting Tab will be Installed) - 275.00

Complete New Rear Drum Brake Kit with E-Brake - 400.00

Front Economy Style Front Disk Brake Kit with Finned Calipers - 600.00

31 Spline New Rear End Axles with Bearings & Retaining Plates - 575.00

Master Cylinder  - 200.00



Total 19,920.00









Jitney / Walden "Ultimate Hi-Boy Chassis" (Motor & Trans Not Included)

$19,920.00Price
